Feature
1. Industrial-Grade High-Resolution Solution
- 1,280×1,024 ultra-HD resolution with 12μm VOx detector
- Compact 29×29mm industrial form factor (24.5g)
- Advanced thermal sensitivity (<40mK NETD)
- Optimized for critical industrial applications
2. Unmatched Imaging Performance
- Mega-pixel clarity reveals fine thermal details:
- Enhanced micro-temperature differences
- Superior long-range recognition
- Pinpoint defect detection capability
- Intelligent image processing:
- Adaptive dynamic range optimization
- Real-time noise reduction
- Target enhancement algorithms
3. Comprehensive Lens Ecosystem
- Professional lens portfolio:
- Wide-angle (45°) for area monitoring
- Standard (25°) for general inspection
- Telephoto (12°) for precision measurement
- Expert consultation service for optimal lens selection
- Rapid configuration for different scenarios:
- Electrical inspections
- Process monitoring
- R&D laboratories
4. Industrial Reliability Features
- 24/7 continuous operation capability
- Precision temperature measurement (-20°C to +1500°C extended range)
- Robust mechanical design:
- Vibration-resistant construction
- Thermal-stable calibration
-
IP54 protective rating
Specification
| Performance Indicators | |
| Detector Type | Uncooled VOx infrared detector |
| Resolution | 1280×1024 |
| Detector Frame Rate | 30Hz |
| Pixel Pitch | 12μm |
| Spectral Band | 8~14μm |
| NETD | ≤50mK at 25℃,F#1.0 |
| Image Adjustment | |
| Brightness/Contrast Adjustment | Manual/Automatic/Linear |
| Polarity | Black-hot/White-hot |
| Palette | Support |
| Image Processing | TEC-less temperature control algorithm, digital filtering noise reduction, and digital detail enhancement. |
| Mirroring | Horizontal/Vertical/Diagonal |
| Power Supply | |
| Power Supply Range (typical) | 4.0~5.5VDC, 4.1~5.5V DC supported by user extension components. |
| Typical Power Consumption at 25°C Without Extension | 0.9W |
| Interface | |
| Digital Video | 14Bit or 8Bit LVCMOS/MIPI, BT1120 |
| Extension Components | USB3.0 |
| Control Interface | UART（3.3V） |
| Temperature Measurement Performance | |
| Measurement Range | / |
| Measurement Accuracy | / |
| Measurement Tool | / |
| Physical Characteristics | |
| Dimensions (Without lens and extension components) | 29mm × 29 mm × 18.9mm |
| Weight (3.2mm, without extension components) | 24.5g |
| Lens Model | 10mm,35mm,50mm,75mm |
| Environment Adaptability | |
| Operating Temperature | -40℃～+70℃ |
| Storage Temperature | -45℃～+85℃ |
| Humidity | 5~95%, non-condensing |
| Product Certification | RoHS2.0 |
Application Scenarios
- Industrial Temperature Measurement
- Security Monitoring
- UAV Pod
- Machine Vision
